6
Fig. 4 — 50PEC18 Bottom Return Cabinet Dimensions — Right Hand Piping
NOTES:
1. Dimensions are shown in inches. Dimensions in parentheses are in millimeters.
2. Access is reduced if optional disconnect box is selected.
3. Optional autoflow valve, motorized water valve and disconnect box are shown. a50-8340
30˚
11.50
(292)
4.90
(125)
3.50
(89)
25.90
(658)
DAMPER OPENING
54.00
(1372)
1.63
(41)
11.75
(298)
9.81
(249)
0.59
(15)
21.00
(533)
4.90
(125)
REAR VIEW
AIR
INLET
DISCHARGE
AIR
1.75
(44)
3.00
(76)
0.75 (19)
R.H. PIPE AND
ELECTRIC AREA
(NOTE 2)
1.00(25)
1.00 (25)
4.50
(114)
20.00
(508)
12.00
(305)
10.00
(254)
BOTTOM VIEW
5.00
(127)
16.00
(406)
FRONT VIEW
CONTROL ACCESS DOOR
AIR INLET AREA
54.00
(1372)
39.50
(1003)
1.75
(44.5)
54.00
(1372)
3.53
(90)
SIDE
VIEW
RH REAR
ACCESS
(NOTE 2)
2.12 (54)
6.88
(174)
Filter located inside and at
top of air inlet area. Rotate
filter latch forward, filter rack
can be pulled forward 75 to
100 mm for filter access
