Model 5128/29 Fire Slave Communicator Installation Manual
32 150805
S
ECTION
7
T
ROUBLESHOOTING
7.1 System Messages
Table 7-1 shows the messages that could appear on the LCD of the model 5230 annunciator. If you have a
problem that is not covered here, contact Technical Support at 800-328-0103 for assistance.
Note: When step programming mode is in use and the 5230 annunciator powers up, the LCD displays messages that
describe conditions currently in effect.
7.2 Silencing Troubles
The built-in audible trouble buzzer can be silenced by pressing the silence button (see Figure 3-1).
Note: Silencing a trouble condition does not correct the trouble condition. The trouble buzzer will re-activate every 24
hours if the trouble condition remains uncorrected or if a new trouble condition occurs.
Table 7-1: Explanations of Display Messages
5230 MESSAGE EXPLANATION/ACTION TO BE TAKEN
AC LOW AC power has been lost. Check connection to AC power source.
ALARM ZONE 1-4 An alarm condition exists in the indicated zone.
BAD EEPROM
5230 buzzer goes on and off. Most likely cause is a bad EEPROM chip, which is not an installer-serviceable part.
Contact Technical Support if you need to arrange for a warranty exchange.
Line 2: CALLING COMPUTER System is calling remote computer (for up- or downloading).
Line 2: REPORTING The system is reporting to the central station.
REPORTING An event is being reported to the central station.
SYSTEM NORMAL No trouble, alarm, or other condition exists.
TIME? The 5128/29 is in Time Set mode.
TROUBLE (line 1)
TROUBLE ZONE # (line 2) Sprinkler supervisory trouble.
TROUBLE (ZONE 1-4) A trouble condition exists in the indicated zone.
TROUBLE DIALER After making the programmed number of attempts, the dialer has not been able to
communicate with the central station. (This is a dialer failed condition.)
TROUBLE LINE 1 A trouble condition exists on phone line 1.
TROUBLE LINE 2 A trouble condition exists on phone line 2.
TRY AGAIN A keystroke error has been made. Press and enter the correct keystrokes. CLEAR
