4 dc power connection – SilentKnight 5129 Digital Alarm Communicator Transmitter User Manual
Page 14
Model 5128/29 Fire Slave Communicator Installation Manual
10
150805
3.4
DC Power Connection
Connect DC power to the 5128/29 as shown in Figure 3-3.
Figure 3-3 DC Power Connections
Red
Black
Negative
Power from
Control Panel
Positive
Power from
Control Panel
18-40 VDC rectified power
(See Figure 3-2 for cable
clamp installation)
Supervised
