Programming
150805 23
Table 5-2: Programming Form
Step # /
From
Menu
Option Description
Your Choice
(D) = Default
1
System
Menu ZONE ACTIVATION Select input type.
0 = Dry contact input
1 = Active high input
2 = Currently not available. Do not select. Dry contact (D)
Active high
2
System
Menu ZONE SUPERVISED Yes = All zones supervised
No = All zones unsupervised Yes (D)
No
3
System
Menu LATCH SPRINKLER Yes = When the sprinkler zone shorts for a duration longer than the Zone
Response (set in steps 8 through 11), the annunciator remains active until
reported or manually silenced.
No = When the sprinkler zone shorts for a duration longer than the Zone
Response (set in steps 8 through 11), the zone will follow system status
and indicate a supervisory on that zone for the duration of the faulted
condition.
Yes (D)
No
4
System
Menu CHANNEL #1 TYPE Alarm input
0 = Fire
1 = Sprinkler Fire (D)
Sprinkler
5
System
Menu CHANNEL #2 TYPE Trouble input
0 = Fire
1 = Sprinkler Fire (D)
Sprinkler
6
System
Menu CHANNEL #3 TYPE Supervisory input
0 = Fire
1 = Sprinkler Fire
Sprinkler (D)
7
System
Menu CHANNEL #4 TYPE Alarm input
0 = Fire
1 = Sprinkler
2 = Undefined: For other fire related signalling. Fire (D)
Sprinkler
Undefined
