Reporting
150805 31
6.1 Reporting Codes
Table 6-1 list the events sent by the 5128/29 and the code that is sent for that event by the type of reporting
format used.
Table 6-1: Event and Reporting Code by Format
Event SIA8 & 20 SK4/2 3/1 1400 &2300 BFSK14 & 23 Contact ID
Fire Alarm 1-4 FA1 - FA4 *01 - 04 Alarm Code 01 - 04 1 110 001 - 1 110 004
Fire Alarm Restore 1-4 FH1 - FH4 *21 - 24 Restore Code E1 - E4 3 110 001 - 3 110 004
Fire Trouble 1-4 FT1 - FT4 61 - 64 Trouble Code F1 - F4 1 373 001 - 1 373 004
Fire Trouble Restore 1-4 FJ1 - FJ4 71 - 74 Restore Code E1 - E4 3 373 001 - 3 373 004
Sprinkler Supervisory 1-4 SS1 - SS4 01 -04 Sprinkler Code 01 - 04 1 203 001 - 1 203 004
Sprinkler Supervisory Restore 1-4 SR1 - SR4 21 - 24 Restore Code E1 - E4 3 203 001 - 3 203 004
Sprinkler Trouble 1-4 ST1 - ST4 61 - 64 Trouble Code F1 - F4 1 203 001 - 1 203 004
Sprinkler Trouble Restore 1-4 SJ1 - SJ4 71 - 74 Restore Code E1 - E4 3 203 001 - 3 203 004
Untyped Alarm UA4 04 Alarm Code 04 1 140 004
Untyped Alarm Restore UH4 24 Restore Code E4 3 140 004
Untyped Trouble UT4 64 Trouble Code F4 1 370 004
Untyped Trouble Restore UJ4 74 Restore Code E4 3 370 004
AC Trouble AT0 60 Trouble Code FA 1 301 000
AC Restore AR0 70 Restore Code EA 3 301 000
Trouble Phone Line #1 LT1 31 Trouble Code FB 1 351 000
Restore Phone Line #1 LR1 35 Restore Code EB 3 351 000
Trouble Phone Line #2 LT2 32 Trouble Code FC 1 352 000
Restore Phone Line #2 LR2 36 Restore Code EC 3 352 000
Communications Failure Line #1 YC1 31 Trouble Code FB 1 351 000
Communications Restore Line #1 YK1 35 Restore Code EB 3 351 000
Communications Failure Line #2 YC2 32 Trouble Code FC 1 352 000
Communications Restore Line #2 YK2 36 Restore Code EC 3 352 000
Manual Test RX0 30 Test Code EE 1 601 000
Automatic Test (Normal) RP0 30 Test Code EE 1 602 000
Automatic Test (Abnormal) RYO 39 Test Code EE 1 608 000
Downloading Passed RS0 30 Test Code EF 1 412 000
Downloading Failed RU0 30 Test Code FF 1 413 000
Data Lost RT0 39 Trouble Code FE 1 354 000
*
“02” and “22” will never be reported. Channel/Zone 2 is a trouble indication only that will transmit only “62” and “72.”
