P6sP-090(c/D)a
Factory Standard: 1.5Hp Downflow Performance Chart ‡ Indicates Factory Sheave Setting
External
Unit
Static
(in-Wg)
Operating
@ 230 or
460 Volts
Adjustable Motor Sheave Setting
Fully
Closed
1/2
Turn
Open
1
Turn
Open
1.5
Turns
Open
2
Turns
Open
2.5
Turns
Open
3
Turns
Open
3.5
Turns
Open
4
Turns
Open
4.5
Turns
Open ‡
5
Turns
Open
5.5
Turns
Open
6
Turns
Open
0.1
CFM 3620 3515 3400 3285 3187 3089
RPM 893 870 847 823 803 783
kW 1.47 1.35 1.25 1.15 1.06 0.98
0.2
CFM 3590 3477 3363 3248 3132 3031 2930
RPM 918 895 872 848 825 805 785
kW 1.50 1.39 1.28 1.18 1.08 1.00 0.92
0.3
CFM 3549 3441 3331 3220 3097 2973 2864 2755
RPM 941 920 897 873 850 827 807 786
kW 1.55 1.44 1.33 1.22 1.12 1.02 0.94 0.86
0.4
CFM 3532 3419 3306 3185 3063 2932 2800 2687 2574
RPM 965 944 923 899 876 853 830 809 788
kW 1.58 1.47 1.36 1.25 1.14 1.05 0.95 0.87 0.80
0.5
CFM 3382 3267 3152 3021 2889 2750 2611 2484 2357
RPM 968 947 925 902 878 855 832 811 790
kW 1.50 1.39 1.28 1.17 1.07 0.97 0.87 0.80 0.72
0.6
CFM 3339 3239 3115 2991 2846 2700 2549 2398 2257
RPM 990 972 950 928 904 881 857 833 813
kW 1.52 1.41 1.30 1.20 1.09 0.99 0.89 0.80 0.72
0.7
CFM 3294 3184 3074 2942 2810 2652 2493 2316
RPM 1011 993 975 953 930 907 884 859
kW 1.55 1.44 1.33 1.22 1.11 1.01 0.90 0.81
0.8
CFM 3136 3024 2911 2762 2613 2435 2257
RPM 1013 995 978 955 933 910 887
kW 1.45 1.35 1.24 1.13 1.03 0.92 0.81
0.9
CFM 3082 2979 2850 2720 2548 2376
RPM 1033 1016 998 980 958 935
kW 1.48 1.36 1.25 1.15 1.03 0.92
1.0
CFM 3012 2897 2789 2647 2505 2301
RPM 1054 1036 1019 1001 984 961
kW 1.48 1.38 1.26 1.15 1.04 0.93
1.1
CFM 2834 2718 2572 2407 2242
RPM 1058 1041 1024 1005 987
kW 1.36 1.27 1.16 1.05 0.93
1.2
CFM 2630 2485 2335
RPM 1061 1045 1028
kW 1.26 1.16 1.04
1.3
CFM 2405 2237
RPM 1064 1049
kW 1.14 1.04
Values includes losses for: Unit Casing, 2” Disposable (Pleated) Filters & Dry Evaporator Coil
When utilized with H5HK Heater kits, not all operational points shown may be available for use. Refer to the H5HK Installation
Instructions to determine the minimum airflow requirements of the applicable heater assembly.
Deduct 250 Cfm for electric heater kits
table 7. Blower Performance for P6sP-090(c,D)a series
(7.5 ton Downflow Models only)
