14
conDEnsEr EnD
HEat EXcHanGEr EnD
42 3/4 (1085)
4
(102)
9
(228)
9
(228)
3 1/2
(88)
1 3/4
(44)
5
(127)
External Power Entry
Recommended unit
disconnect mounting
location
Rating
Label
15 3/8
390
AIR AIR
Optional
Economizer
Hoods
BOTTOm PAn TOP VieW
Figure 10. P6sP - 072 series (continued)
PHYsIcal Data - continued
Dimensions shown in inches (mm)
†
5-3/4 (146)
16 1/2
(419)
30 1/2
(775)
Discharge Air
Opening
7 (178) 7 (178)
Return Air
Opening
16 1/2
(419)
30 1/2
(775)
Power
Entry
8 3/4
(222)
62 (1575)
101 1/4 (2572)
