16
4 (102)
Recommended Unit
Disconnect Mounting
Location
Rating Label
HEat EXcHanGEr EnD
BOTTOm PAn TOP VieW
†
5-3/4 (146)
16 1/2
(419)
30 1/2
(775)
Discharge Air
Opening
7 (178) 7 (178)
Return Air
Opening
16 1/2
(419)
30 1/2
(775)
Power
Entry
8 3/4
(222)
62 (1575)
101 1/4 (2572)
conDEnsEr EnD
Airflow Airflow
Compressors (x2)
PHYsIcal Data - continued
Dimensions shown in inches (mm)
Figure 11. P6sP - 090 series (continued)
