20
Model
number
P6sP-
nominal unit
Voltage
High static
Kit #
single circuit (unit + Heater Kit) see note
Mca MoP
Factory unit Electrical Data:
9 kW 18 kW 30 kW 35 kW 9 kW 18 kW 30 kW 35 kW
-072C 208 - 230 V
Factory Std.
30 - 31 50 - 57 80 - 91 - n/a - 45 - 45 50 - 60 80 - 100 - n/a -
-072D 460 V 17 29 46 - n/a - 20 30 50 - n/a -
-090Ca 208 - 230 V
Factory Std.
39 - 39 51 - 58 81 - 92 97 - 110 50 - 50 60 - 60 90 - 100 100 - 110
-090Da 460 V 19 30 46 55 20 30 50 60
-120Ca 208 - 230 V
Factory Std.
45 - 45 51 - 58 81 - 92 97 - 110 60 - 60 60 - 60 90 - 100 100 - 110
-120Da 460 V 22 30 46 55 25 30 50 60
Medium & High static Drive Electrical Data:
-072C 208 - 230 V 920609 32 - 33 51 - 58 81 - 92 - n/a - 50 - 45 60 - 60 90 - 100 - n/a -
-072D 460 V 920560 18 30 46 - n/a - 25 30 50 - n/a -
-090Ca 208 - 230 V
921481
40 - 40 53 - 60 83 - 94 99 - 112 50 - 50 60 - 60 90 - 100 100 - 125
-090Da 460 V 19 31 47 56 25 35 50 60
-120Ca 208 - 230 V
921645
47 - 47 53 - 60 83 - 94 99 - 112 60 - 60 60 - 60 90 - 100 100 - 125
-120Da 460 V 23 31 47 56 30 35 50 60
notE: Nordyne specifically recommends the use of the 917468 Dual Circuit adapter kit for all applications of H5HK 30kW & 35kW Electric
Heat Kits.
table 3. P6sP Electrical Data - single supply circuits
