Reznor P6SP Unit Installation Manual - Manual (Page 17)

17
FrOnT VieW
TOP VieW
reAr VieW
Evaporator
Filters (4)
Blower
Assembly
Condenser
Fan
Condenser
Fan
Corner “A”
Corner “B”
Corner “D”
Corner “C”
A
B
Optional
Hail Guard
Hood
16
(406)
30-3/4 (781)
101-1/2 (2578)
Control Access
Blower Access
Condensate
Drain
Field Wiring
†
(Electric Element
Access)
2 (51)
4 (102)
Recommended Unit Disconnect Location
16 1/2
30 (762) (419)
16 1/2
7 1/4
4 (102)
30
(762)
(184)
(419)
(178)
7
(419)
16 1/2
Filter Access
Coil
Condenser Heat
Exchanger
Access
Opening*
Horizontal
Opening*
Return Air
Horizontal
Discharge
Air
4 (102)
(1403)
55 1/4
†
shown with optional horizontal duct panels
Figure 12. Physical Data - P6sP - 120 series
PHYsIcal Data - continued
Dimensions shown in inches (mm)
