The Novak Sentry Data Logger is equipped with a number of sensors that are used to monitor various
parameters. Except the input harness, all other sensors are optional. Because the device is powered via the
vehicle’s BEC or receiver pack, either the speed control input harness or the servo input harness must be
plugged into the device.
WARNING!
The maximum input voltage is 7 volts. Using more than 7 volts will
damage the Sentry Data Logger and void the
product warranty
.
IMPORTANT
All of the sensors should plug into the data logger with black
wires facing toward the outside edge. Take special care to plug all of the
sensors in the correct slot with the correct polarity. Reverse battery polarity can
damage the data logger and void
. Disconnect the battery
