Page 11 – Neuspeed 49.10.95 User Manual
Page 11
FUEL PRESSURE
REGULATOR
EVAP CANISTER
PURGE VALVE
5/16 T-FITTING
LEAK DETECTION
PUMP
BYPASS
VALVE
AIR PUMP
FUEL INJECTION AIR ASSIST
CHECK VALVE
MASS AIR FLOW
SENSOR
THROTTLE BODY
CHECK VALVE
BRAKE BOOSTER
AIR BOX
AIR INTAKE HOSE
PCV HEATING
ELEMENT
VACUUM SCHEMATIC
MASS AIR FLOW
SENSOR
AIR BOX
AIR INTAKE HOSE
EXPANSION TANK
TO HEATER
COOLANT SCHEMATIC
