NEUSPEED • 3300 Corte Malpaso • Camarillo, CA 93012 • 805.388.7171 • 805.388.0030 FAX

www.neuspeed.com

P-FLO KIT FOR 2004-06 TOUAREG V6 3.2L

PART # 65.10.95

INSTALLATION INSTRUCTIONS

PARTS LIST:

1 – P-FLO SS BRACKET

1 – NEUSPEED AIR FILTER

1 – MINI FILTER

1 – SILICONE 90° ELBOW

1 – BILLET ALUMINUM ADAPTER

2 – ¼-20 X ¾” HEX HEAD BOLT

2 – ¼-20 NYLOC NUT

1 – 3½” HOSE CLAMP

1 – 3¾” HOSE CLAMP

TOOLS REQUIRED: 1 – FLAT HEAD SCREWDRIVER

1 – PHILIPS SCREWDRIVER

1 – RATCHET HANDLE

1 – 7/16” WRENCH

1 – 7/6” SOCKET

1 – 10mm SOCKET

1 – CHANNEL LOCK PLIERS

1. If equipped, lift off the passenger side engine

compartment cover to expose air filter box.

2. Disconnect MAF (mass air flow) sensor

electrical connector, plastic intake hose
connected to MAF and rubber hoses that are
attached to air box with metal clips.

3. Disconnect air pump hose connecting to air

box cover. Squeeze plastic ring, located at
lower front section of air box, to unlock.

4. Undo two metal clips on top of the air box

and remove cover.

5. Remove upper air box mounting bolt (10mm

hex), then pull out air box.

Air

Pump

Hose

Metal Clip

MAF Connector
