Biopointe Central User’s Manual
Appendix A 70
Table 4.6(c): Alarm Events (Trace Event)
Identifier
(hex)
Identifier
(dec)
Description
1
0x30
48
Alarm Activated
2
0x31
49
Alarm Deactivated
3
0x81
129
Activated Alarm was Acknowledged and Disabled
The event, [Alarm Activated] is recorded whenever the alarm is triggered. The alarm will only be
triggered if the AlarmType property is NOT
The alarm can be triggered under a few types of conditions.
For example, the alarm can be triggered if the door switch sensing is found to be different from the
DoorSwitchSense property. As an example, if the DoorSwitchSense property is
DoorSwitchSense property is
will also be activated. When the condition is correct, the alarm stops and the event, [Alarm
Deactivated] will be recorded.
In addition, the alarm can also be triggered when the Door Override Switch is closed and when the
Tamper Switch is opened.
When the alarm has been activated, it can be acknowledged and stopped by forcing the
AlarmType property to
and Disabled] will be recorded.
Notes on Alarm Events Logs and Door / Device Tamper Events Logs :
The following events trigger the alarm:
1. Door Override Switch was closed.
2. Tamper Switch was opened.
3. Door Switch Sensing was found to be reverse.
The first 2 events already have their own event description, namely, [Door Override Switch
Closed] and [Tamper Switch Opened]. To avoid generating too many logs, the event, [Alarm
Activated] will not be recorded although the alarm will be triggered.
Table 4.6(d): System Power Up (Trace Event)
Identifier
(hex)
Identifier
(dec)
Description
1
0x90
144
System Powered Up
2
0x91
145
Startup Error
When the system is successfully powered up, the event, [System Powered Up] will be recorded.
When the system fails to power up successfully, the event, [Startup Error] will be recorded.
