Corinex ADSL2+ Wireless Gateway G Configuration
Corinex ADSL2+ Wireless Gateway G
9. Select the quality of service (QOS); leave the default value if you are unsure or
the ISP did not provide this information.
10. Click the apply button to complete the connection setup. This will temporarily
save this connection.
11. To make the change permanent, click on Save all settings in the left menu.
12. For connection, click on Connect.
The following table shows a description of the Static setting options:
Field
Description
Encapsulation
Two options are provided: Logical Link Control (LLC)
and Virtual Channel (VC).
IP Address
IP address of the static connection.
Mask
Subnet mask provided by your ISP.
Gateway
Your gateways IP address.
Default Gateway
If checked, this connection becomes the default gateway
to the Internet.
DNS
Domain Name Server address provided by your ISP.
Mode
The Bridged and Routed modes are available.
The VLAN Settings include the options showed in following table:
Field
Description
Sharing
This is where you enable/disable sharing. The VLAN needs
to be selected to create VLAN.
VLAN ID
VLAN Identification
Priority Bits
Priority is given to a VLAN connection from 0-7, 0 means
highest priority.
