38
Corinex ADSL2+ Wireless Gateway G Configuration
Corinex ADSL2+ Wireless Gateway G
4. Under PPP Settings, select the encapsulation type (LLC or VC).
Note: If you are not sure just use the default mode.
5. Under PVC Settings, enter the values of VPI and VCI settings.
Note: Your DSL service provider or your ISP will supply these.
6. Select the quality of service (QOS); leave the default value if you are unsure or
the ISP did not provide this information.
7. Click the apply button to complete the connection setup. This will temporarily
save this connection.
8. To make the change permanent, click on Save all settings in the left menu.
9. For connection, click on Connect.
The PPP options include following settings:
Field Description
Encapsulation The technique used by layered protocols in which a layer
adds header information to the protocol data unit (PDU)
from the layer above. As an example, in Internet termi-
nology, a packet would contain a header from the physi-
cal layer, followed by a header from the network layer
(IP), followed by a header from the transport layer (TCP),
followed by the application protocol data. Two options
are provided: Logical Link Control (LLC) and Virtual
Channel (VC).
Username Your user name for the PPPoA access; this is provided by
your DSL service provider or your ISP
Password The password for the PPPoA access; this is provided by
your DSL service provider or your ISP
Idle Timeout Specifies that PPPoA connection should disconnect if the
link has no activity detected for n seconds. This field is
used in conjunction with the On-Demand feature. To en-
sure that the link is always active, enter a 0 in this field.
Keep Alive When on-demand option is not enabled, this value specifies
the time to wait without being connected to your provider
before terminating the connection. To ensure that the link
is always active, enter a 0 in this field
