Appendix C: Mode Switch Bank Settings and Optional Installations
C-4
6E122-26, 6E132-25, 6E123-26 and 6E133-25 User’s Guide
C.3
INSTALLING OPTIONAL FAST ETHERNET
INTERFACE MODULES
shows the location of the Fast Ethernet Interface Module
connectors on the 6E12X-26 board for port slots 25 and 26.
Figure C-2
Fast Ethernet Interface Module Connector Location
NOTE
For instructions on installing a High Speed Interface Module
(HSIM) in the 6E13X-25, refer to the applicable HSIM
documentation.
Optional Fast
Ethernet Interface
Modules
Connectors
