Chapter 5: Local Management
5-86 6E122-26, 6E132-25, 6E123-26 and 6E133-25 User’s Guide
Figure 5-30 Port Redirect Function Screen
The following definitions briefly explain each field of the Port Redirect
Function screen:
Source Port (Read-only)
Shows which ports are currently set as source ports.
Destination Port (Read-only)
Shows which ports are currently set as destination ports.
Remap Errors (Read-only)
Displays whether the corresponding source ports are configured to send
errored frames to the destination ports, or to drop all errored frames
before forwarding traffic.
Source Port [ n] (Selectable)
Allows a selected port [n] to be changed to a source port.
Destination Port [ n] (Selectable)
Allows a selected port [n] to be changed to a destination port.
Firmware Revision: XX.XX.XX
Port Redirect Function
1960_22
BOOTPROM Revision: XX.XX.XX
Source Port:
1
1
1
2
2
3
3
3
Destination Port:
2
3
4
1
3
4
5
6
Module Type: 6E122-26
Slot Number: X
Remap Errors:
ON
ON
ON
OFF
OFF
ON
ON
ON
============ ============ ============
6E122-26 LOCAL MANAGEMENT
Event Message Line
SAVE PREVIOUS
RETURN
RETURN NEXT
Source Port [1] Destination Port [1] Status [ADD]
EXIT
Errors [ON]
