Data Acquisition Expansion Pod 7
Row 1 Row 2 Row 3
1 – DGND 18 – GPCTR0_OUT 34 – FREQ_OUT
2 – PFI8 19 – PFI7 35 – PFI6
3 – PFI9 20 – GPCTR1_OUT 36 – PFI5
4 – PFI4 21 – PFI3 37 – +5V
5 – PFI2 22 – DGND 38 – PFI1
6 – SCANCLK 23 – DIO2 39 – PFI0
7 – DIO7 24 – DIO3 40 – +5V
8 – DIO6 25 – DIO4 41 – DIO1
9 – DIO5 26 – DGND 42 – DIO0
10 – AIGND 27 – ACH14 43 – AIGND
11 – AISENSE 28 – ACH13 44 – ACH6
12 – AIGND 29 – ACH12 45 – ACH5
13 – DAC_1_OUT 30 – ACH11 46 – ACH4
14 – AIGND 31 – ACH10 47 – ACH3
15 – AOGND 32 – ACH9 48 – ACH2
16 – SENSOR_EXC 33 – ACH8 49 – ACH1
17 – AIGND 50 – ACH0
Recommended Software to Gather and Analyze
Data
To use the DAQ Expansion Pod and the NI DAQCard, you have two
options:
You can develop your own application-specific software.
(Consult the documentation that came with your NI DAQCard or
contact National Instruments for more information.)
Purchase LabVIEW and LabVIEW PDA from National
Instruments.
LabVIEW software allows you to generate applications for your
desktop computer. LabVIEW PDA, an add-on software module, lets
you load and run your applications on your Allegro CX. To purchase
LabVIEW software, visit http://www.ni.com/labview/. To read more
about how LabVIEW works with the Allegro CX, visit the following
sites:
▲


