Page 19
Data Acquisition Expansion Pod 19
Locating Switches on the Schematic
The Appendix shows a five-page schematic. The schematic provides
an in-depth view of the DAQ Expansion Pod, including switch
settings. A table at the beginning of the the Appendix lists each
switch’s designator as it appears in the schematic.
▲
