Juniper Systems Allegro DAQ User Manual
Page 14
14 User’s Guide
Signal
name
Reference
Direction
Description
CTR 0
OUT
D GND
Output
Counter 0 Output Signal—As
an output, this pin emits the
Ctr0InternalOutput signal.
CTR 1
OUT
D GND
Output
Counter 1 Output Signal—This
pin emits the Ctr1InternalOutput
signal.
FREQ
OUT
D GND
Output
Frequency Output Signal—This
output is from the frequency
generator.
Table used with permission from National Instruments
.
