Page 6
6 User’s Guide
Chapter 3: Connecting the Expansion Pod
This chapter provides the following:
A diagram of the 50-pin D connector
A chart with pinout assignments for the connector
Software recommendations for the DAQ Expansion Pod
Connector Diagram and Pinout Chart
The following diagram illustrates the pinout for the 50-pin D
connector as viewed from the outside of the DAQ Expansion Pod.
The chart on the next page shows the pinouts assigned to each row.
▲
Row 1
Row 2
Row 3
