72
SECTION 4 E6H/E6M Inputs & Outputs
The E6H/E6M has several types of optional inputs and outputs. These are:
- Idle Speed Control
- O
2
Closed Loop Control
- Auxiliary In (Aux In)
- Auxiliary Out (Aux Out)
- Digital Output (Digital Out 1-2)
All outputs except the Digital Outputs are available all the time – irrespective of the engine
configuration. Idle Speed and O
2
Closed Loop Control are not general purpose outputs – they
can only be used for the stated purpose. Aux Out and Digital Out 1-2 are general purpose
outputs – they can be selected to control any devices from a list of options.
The number of available digital outputs depends on the engine configuration, direct fire and
sequential fuel require more outputs and consequently reduce the number of outputs available
for ancillary control. This means you are limited to the Auxiliary Output to control output
devices.
Below is a summary of the general purpose outputs and the options list they contain:
Output Channel
Output Description
Aux Out Digital Out 1–2
Turbo Wastegate
r [
Bypass Air Control (BAC)
r [
Dual Intake Valve
r [
Torque Convertor Control
r [
Thermofan
r [
Intercooler Fan
r [
Shift Light
r [
Aux Fuel Pump
r [
Stall Saver
r [
Staging Signal
[ [
Turbo Timer
r [
NOS Switch
r [
Anti-Lag Switch
r [
Ignition Bypass
[ r
Tacho Output
[ r
Ignition Toggle
[ r
