9.2 Loading Maps and Identification
While the ECU system is ONLINE, you can load previously saved map information from
computer disk into your Haltech ECU. The contents of the ECU are erased and replaced with
the new maps you have chosen. If you are OFFLINE, you can load previously stored maps,
view and edit them, then save them for later use.
To load new complete maps and identification into the ECU, you must first be ONLINE.
Press
ƒφ
then
λ
from the Files sub-menu. The load command erases the contents of the ECU
and replaces it with the set of maps stored on the disk you are loading into the system.
Note: Remember to save any maps currently in the ECU that you wish to retain
before loading new maps from a disk since this action will overwrite any maps
currently in the ECU.
Although the loading of the maps should not affect the running of the ECU, it is best that the
engine is not under load while maps are being loaded.
Select the name of the map you wish to load by using the arrow keys to highlight that name
and press return. If there are more files then will fit in the window, you can scroll down
through the extra files using the arrow keys. If you know the name of the file, you may type it
in. The computer will then pause to ask if everything is OK before continuing the load. If you
are ready to proceed, press
Ψ
. If there is an error, abort by pressing
Ν
. The load will take
approximately two minutes.
9.3 Upgrading from E6S
To make it easier to upgrade from the E6S family of systems to the E6H/E6M, there is a
function under the File menu called Import E6S maps. This allows you to connect an
E6H/E6M to an existing E6S wiring loom and load E6S maps into an E6H/E6M. All
information in the E6S maps will be retained and loaded into the E6H/E6M.
Note that the Output Options information will be lost and you will have to reset the outputs
you require. This is due to the new hardware in the E6H/E6M. Unfortunately, an entire E6S
map import is not possible. Your new E6H/E6M should now have all the information loaded
into it and can be operated as normal.
