27
If this message appears check all connections and ensure that the
communications cable is not being interfered with. Also be sure that the
Haltech E6H/E6M unit is receiving power. (i.e.. ignition switch is turned
"on".)
2.5 The Main Menu
When you select ONLINE or OFFLINE mode the Haltech MAIN MENU bar appears. This
menu bar allows access to submenus giving access to maps, file storage/retrieval, engine data
and options.
2.6 How to Quit
Throughout the program you can exit from any application by using the menu bars or hot
keys. Pressing
♣θ
in any page will prompt you to exit the program (i.e.. pressing
θ
while
holding down the
♣
key). If you wish to exit, press
Ψ
at the prompt.
2.7 Checking the Engine Data
The engine data option can only be used when the system is ONLINE. This function allows
all of the engine data variables to be displayed on the screen
This is a very useful function for analysing the engine sensors. To bring up the engine data
press
♣ε
from any application. Otherwise it can be accessed through the menu bar by
pressing
ƒΟ
and then
Ε
for Engine Data.
Do not attempt to start the engine if the Engine Identification has not been set up. Before
continuing check to see if all the sensors are operating correctly by viewing the engine data
page.
