DAD 141.1 Technical Manual, Rev. 2.2 - February 2014 Page 49 of 54
10.12. Save Calibration and Setup
– CS, WP, SS, AS, GI, PI
The calibration and setup parameters can be divided in 4 groups:

Calibration: CM, DS, DP, CZ, CG, ZT, IZ and FD, etc. saved by command CS

Setup: FL, FM, NR, NT, BR, AD, DX and others, saved by command WP

Setpoints: S1, S2, S3, H1, H2, H3, A1, A2, A3 - saved by command SS

Analog outputs: AA, AH, AL, AM - if available - saved by command AS
Note: Calibration data can only be saved if the TAC code is known and preceding the CS command. See the
commands CE and CS in chapter 10.2.
The setup data and the setpoint data will be stored non-volatile in the EEPROM using the WP respective SS
and AS command.
10.12.1. WP Save the Setup Parameters [ Index 0x2066 ]
With this command the settings of the “Filter” (FL, FM), the “No-motion” (NR, NT) and the communication (AD,
BR, DX) will saved in the EEPROM.
Master (PC / SPS) sends Slave (DAD 141.1) responds Meaning
WP OK Setup data saved
WP ERR Error
10.12.2. SS Save Setpoint Parameters [ Index 0x2066 ]
With this command the setpoints (S0, S1), the setpoint hysteresis (H0, H1) and the setpoint allocation (A0, A1)
will be saved in the EEPROM.
Master (PC / SPS) sends Slave (DAD 141.1) responds Meaning
SS OK Setpoint parameters saved
SS ERR Error
10.12.3. AS Save Analogue Output Parameters [ Index 0x2066 ]
With this command the action (AA), the analog low (AL), the analog high (AH) and the output mode (AM) will be
saved in the EEPROM.
Master (PC / SPS) sends Slave (DAD 141.1) responds Meaning
AS OK Analog output parameters saved
AS ERR Error
10.12.4. GI Get an Image File from the EEPROM
Retrieves a HEX-INTEL formatted EEPROM image file from the EEPROM of the source DAD 141.1. The image
file contains all stored information except the calibration data. This image file can be downloaded to any
DAD 141.1 with the same firmware type and revision no. as the source DAD 141.1.
10.12.5. PI Download an Image File to the EEPROM
Downloads a HEX-INTEL formatted EEPROM image file to the target DAD 141.1 EEPROM. The image file
contains all stored information except the calibration data.
Attention: The target DAD 141.1 must have same firmware type and revision no. as the source DAD 141.1.
