DAD 141.1 Technical Manual, Rev. 2.2 - February 2014 Page 18 of 54
7.7. Menu 5
– Analog Output
5 Analog output setup (Menu 5.1 to 5.5)
5.1 Weight value for minimum analog output (command AL)
- Set the weight value which corresponds to minimum output
Examples for scale 0 … 3 000kg
Minimum 0kg or with 600kg preload
- output mode 4 … 20mA: 0kg = 4mA - setting 00000
600kg = 4mA - setting 00600
- output mode 0 … 20mA: 0kg = 0mA - setting 00000
600kg = 0mA - setting 00600
5.2 Weight value for maximum analog output (command AH)
- Set the weight value which corresponds to maximum output
Examples for scale 0 … 3 000kg
Maximum 3 000kg
- output mode 4 … 20mA: 3 000kg = 20mA - setting 03000
- output mode 0 … 20mA: 3 000kg = 20mA - setting 03000
5.3 Analog output base (command AA)
gros - analogue output follows Gross value
net - analogue output follows Net value
PEA - analogue output follows Peak value (Maximum)
AUEr - analogue output follows Average value
HoLd - analogue output follows Hold value
PP - analogue output follows Peak - Peak value
UALL - analogue output follows Valley value (Minimum)
dISP - analogue output follows Display value
oFF - analogue output is switched OFF
5.4 Analog output mode (command AM)
4_20 4 to 20mA
0_20 0 to 20mA
0 _ 5 0 to +5V
0 _ 10 0 to +10V
- 5 _ 5 -5 to +5V
- 10 _ 10 -10 to +10V
5.5 Test current output range 0…20mA
Set a mA value as a test output signal, independent of the
applied load/weight - e.g. 004.000 for 4mA
