10. Commands Description
For better clarity, all commands are divided into groups as described on the following pages. Each command
has to be completed with a CR (Enter), which is shown in the following tables as “ “.
For each command, the Modbus Index is displayed in brakets [
Index 0xNNNN ] and explained in the separate
manual ‘Modbus Communication’. If case of no index mentioned, the command is not available for
Modbus RTU or TCP.
10.1. System Diagnosis Commands
– ID, IH, IV, IS, SR, RS
Use these commands you get the DAD 141.1 type, firmware version or device status. These commands are
sent without parameters.
10.1.1. ID Get Device Identity [ Index 0x202C ]
Master (PC / SPS) sends Slave (DAD 141.1) responds
ID D:1410
The response to this request gives the actual identity of the active device. This is particularly useful when trying
to identify different device types on a bus.
10.1.2. IH Get Hardware Version
Master (PC / SPS) sends Slave (DAD 141.1) responds
IH H:14100101 FFFFFFFFFFFFFF…
10.1.3. IV Get Firmware Version [ Index 0x202E ]
Master (PC / SPS) sends Slave (DAD 141.1) responds
IV V:0104
The response to this request gives the firmware version of the active device.
10.1.4. IS Get Device Status [ Index 0x2030 ]
Master (PC / SPS) sends Slave (DAD 141.1) responds
IS S:067000 (example)
The response to this request comprises of two 3-digit decimal values (001 and 000), which can be decoded
according to the table below:
Leftmost 3-digit value Rightmost 3-digit value
1 Signal stable (no motion) 1 (not used)
2 Zeroing action performed 2 (not used)
3 Tare active 3 (not used)
4 (not used) 4 (not used)
8 (not used) 8 (not used)
16 (not used) 16 (not used)
32 (Setpoint-) output 0 active 32 (not used)
64 (Setpoint-) output 1 active 64 (not used)
128 (Setpoint-) output 2 active 128 (not used)
The example decodes the result S: 067000 (binary 01000011) as follows:

Signal stable (no motion) [2
0
= 1, LSB]

Zeroing action performed [2
1
= 2]

Tare not active [= 0]

Output 0 active [ = 0]

Output 1 active [2
7
= 64]

Output 2 not active [= 0]
Note: The bits that are not used are set to zero.
