DAD 141.1 Technical Manual, Rev. 2.2 - February 2014 Page 21 of 54
7.10. Menu 8
– Data Communication
8 Data Communication setup (Menu 8.1 to 8.8)
8.1 Baud Rate for COM Port RS 422/485 (use the UP/DOWN buttons) (command BR)
9600 Baud
19200 Baud
38400 Baud
57600 Baud
115200 Baud
8.2 Select RS 422 or RS 485 (use the UP/DOWN buttons)
422 = RS 422 Interface for single DAD 141.1 application
485 = RS 485 Interface for multiple DAD 141.1 application in a bus
8.3 Set Device Address COM Port (RS 422/485) (command AD)
- Set device address for multi-drop to 001 … 255
- Set device address for single point to point applications
- Factory Default: 000
8.4 Select Auto-transmit mode (use the UP/DOWN buttons)
gros - Gross value (command SG)
net - Net value (command SN)
AUEr - Average value (command SA)
SAP - ADC value
ALL - Data string with Gross, Net and Status (command SW)
PEA - Peak value (Maximum) (command SM)
HoLd - Hold value (command SH)
UALL - Valley value (Minimum) (command SV)
PP - Peak to Peak value (command SO)
oFF - set output "1" OFF
8.5 Transmission delay Tx @ COM Port (required for some PLCs) (command TD)
- Transmission delay from 000 … 255 milliseconds
8.6 IP-Address of Ethernet Interface (command NA)
- in decimal notation per 3 characters
- Factory default: 192.168.0.100
8.6.x Example for factory default - AAA.BBB.CCC.DDD
8.6.1 AAA 000192
8.6.2 BBB 000168
8.6.3 CCC 000000
8.6.4 DDD 000100
