DAD 141.1 Technical Manual, Rev. 2.2 - February 2014 Page 34 of 54
10.2.12. AZ Absolute zero point calibration (eCal) [ Index 0x2202 ]
The command AZ is used as reference point for all weight calculations and will setup in mV/V.
Permitted values are ± 32 000 (= ± 3.2000 mV/V).
Master (PC / SPS) sends Slave (DAD 141.1) responds Meaning
AZ Z+0.2796 Request: Zero point @ 0.2796 mV/V
CE E+00017 (example) Request: TAC counter CE17
CE 17 OK Calibration sequence active
AZ_00500 OK New: Zero point @ 0.0500 mV/V
Factory default: 00000d @ 0.0000mV/V input signal.
10.2.13. AG Absolute gain calibration (eCal) [ Index 0x2200 ]
The command AG is used as absolute gain (or measuring range) for all weight calculations and will setup in
mV/V. Permitted values are ± 32 000 (= ± 3.2000 mV/V).
Master (PC / SPS) sends Slave (DAD 141.1) responds Meaning
AG G+0.1868 Request: gain 10 000d @ 0.1868 mV/V
CE E+00017 (example) Request: TAC counter CE17
CE 17 OK Calibration sequence active
AG_+011200_+005000 OK New: gain 5 000d @ 1.12 mV/V
Factory default: 20 000d @ 2.0000mV/V input signal.
10.2.14. CS Save the Calibration Data [ Index 0x2066 ]
This command results in the calibration data being saved to the EEPROM and causes the TAC to be
incremented by 1.
Master (PC / SPS) sends Slave (DAD 141.1) responds Meaning
CE E+00017 (example) Request: TAC counter CE17
CE 17 OK Calibration sequence active
CS OK Calibration values saved
The CS command saves all of the calibration group values, as set by AG, AZ, CZ, CG, CM, DS, DP and ZT.
The command returns ERR and has no updating action unless it is preceded by the CE_XXXXX.
10.2.15. SU Save User Setup in EEPROM
This command saves all the setup data including calibration non-volatile in EEPROM, the TAC counter is
increased by 1. In delivery status the user setup contains the factory default settings (as FD command).
Master (PC / SPS) sends Slave (DAD 141.1) responds Meaning
CE E+00017 (example) Request: TAC counter CE17
CE 17 OK Store sequence active
SU OK User setup stored in EEPROM
10.2.16. RU Restore User Setup to DAD 141.1
This command restores the user setup including the calibration from the EEPROM, the TAC counter is
increased by +1.To activate, the SR command (warm start) must be performed.
Master (PC / SPS) sends Slave (DAD 141.1) responds Meaning
CE E+00017 (example) Request: TAC counter CE17
CE 17 OK Restore sequence active
RU OK Restore from EEPROM
SR OK Activate restored user setup
