DAD 141.1 Technical Manual, Rev. 2.2 - February 2014

Page 28 of 54

9.

Commands

– Overview

Command Short description

Parameter value

Page

AA

Get/set analog output action (base)

0 through 8

47

AD

Communication: Device Address

0...255

46

AG

Absolute gain calibration

± 32000

33

AH

Get/set analog high

-999999 to 999999

47

AI’n’

Assign Input ‘n’ to 1 out of 15 different functions/base

0 to 15

42

AL

Get/set analog low

-999999 to 999999

47

AM

Analog Output Mode Current / Voltage

0 to 5

47

A’n’

Action for Setpoint

‘n’: choose 0 of 8 different base for setpoint ‘n’

0 to 8

44

AS

Save analog output parameters

none

48

AZ

Absolute zero point calibration

± 32000

33

BR

Communication: Baud Rate

9600…115200 baud 46

CE

Calibration: Open Calibration Sequence; Read TAC Counter

0...65535

30

CG

Calibration: Set Calibration Gain (Span) at Load > Zero

1...999999

31

CI

Calibration: Minimum Output Value

–999999...0

30

CL

Communication: Close Device

None

46

CM

Calibration: Set Maximum Output Value

1...999999

30

CS

Save the Calibration Data (CM, CI, DS, DP, etc.) to the EEPROM

None

33, 48

CZ

Calibration: Set Calibration Zero Point

– Scale Without Load

None

31

DP

Calibration: Set Decimal Point Position

0...5

31

DS

Calibration: Set Display Step Size

1, 2, 5, 10, …, 500

31

DX

Communication: Set full-duplex (1) or half duplex (0)

0 or 1

46

FD

Factory default settings: Write Data to the EEPROM (TAC protected)

None

32

FM

Read / modify filter mode: IIR (0) or FIR (1)

0 or 1

35

FL

Digital low pass filter: Filter Cut-off Frequency

0...8

35

GA

Output: Get Triggered Average Value

None

40, 49

GG

Output: Get Gross Value

None

39

GH

Get Hold Value

None

40

GI

Retrieves an image file from the

DAD141.1’s EEPROM

None

48

GN

Output: Get Net Value

None

39

GM

Get Peak (Maximum) Value

None

40

GO

Get Peak tp Peak Value

None

40

GS

Output: Get ADC Sample Value

None

39

GT

Output: Get Tare Value

None

39

GV

Get Valley Value

None

40

GW

Output: Get Data String “Net/Gros/Status“

None

39

H’n‘

Hysteresis for Setpoint H0 (S0) or H1 (S1) or H2 (S2)

-9999...+9999

44

HT

Trigger function: Hold time for Violation of Setpoint Limit

0...65535 ms

45

ID

Device information: Identify Device

None

29

IH

Hardware version

None

29

IN

Logic input: for each Input Status 0 or 1

0000…0011

42

IO

Logic output: for each Output Status 0 or 1

0000…0111

43

IS

Device information: Identify Device Status

None

29

IV

Device information: Identify Firmware Version

None

29

MT

Trigger function: Measuring Time for Averaging

0...3000 ms

49

NA

Network Address

e.g. 192.168.0.100

46

NR

Motion detection: No-motion Range

0...65535 d

34

NT

Motion detection: No-motion Time Period

0...65535 ms

34
