DAD 141.1 Technical Manual, Rev. 2.2 - February 2014 Page 20 of 54
7.9. Menu 7
– Logic Outputs
7 Logic output setup (Menu 7.0 to 7.2)
7.0 Logic Output "0"
7.0.1 Setpoint "0"
7.0.1.1 Setpoint of weight value for switching (command S’n‘ – n=0)
Permitted values +/- 999999
7.0.1.2 Logic output "1" switches ON or OFF (command P’n‘ – n=0)
Use the UP/DOWN buttons for "on" / "oFF"
7.0.2 Hysterisis value "0" (± 'n') (command H’n‘ – n=0)
Permitted values +/- 9999
7.0.3 Base for Setpoint "0" (command A’n‘ – n=0)
gros - Gross value
net - Net value
PEA - Peak value (Maximum)
AUEr - Average value
HoLd - Hold value
PP - Peak to Peak value
UALL - Valley value (Minimum)
Error - Error 4 or 5
oFF - set output "1" OFF
7.0.4 Test logic output "0" (Use the UP/DOWN buttons)
Open/Close contacts using the keyboard
7.0.4.0 Output is OFF
7.0.4.1 Output is ON
7.1 Logic Output "1" (commands S’n‘, P’n‘, H’n‘, A’n‘ – n=1)
As per section 7.0 - but for logic output "1"
7.2 Logic Output "2" (commands S’n‘, P’n‘, H’n‘, A’n‘ – n=2)
As per section 7.0 - but for logic output "2"
