DAD 141.1 Technical Manual, Rev. 2.2 - February 2014 Page 29 of 54
Command Short description Parameter value Page
OM Output Mask – to control hy host 0000…0111 43
ON Open Net weig ht of device ‘n’ 0…255 39
OP Open Device 0…255 46
PI Download a saved image file to the DAD 141.1 ’s EEPROM Image data string 48
P’n’ Polarity of Setpoint ‘n’, n= 0, 1 or 2: On / Off 0 or 1 45
RM Reset Peak (Maximum) Value None 40
RS Device information: Read serial number None 30
RT Scale function: Reset Tare and Switch to Gross Indication None 37
RZ Scale function: Reset Zero Point None 37
SA Auto-transmit: Send Triggered Average Value automatically None 41, 50
SD Trigger function: Start Delay 0... 500 ms 49
SG Auto-transmit: Send Gross Value continuously None 41
SH Auto-transmit: Send Hold Value None 41
SM Auto-transmit: Send Peak (Maximum) Value None 41
SN Auto-transmit: Send Net Value continuously None 41
S ’n‘ Setup of Setpoints S0, S1 and S2 -999999...+999999 44
SO Auto-transmit: Send Peak to Peak Value None 41
SR Reset Firmware (Warm Start) None 30
SS Save the Setpoint Data (S ’n’, H’n’, P’n’, A’n’) to the EEPROM None 48
ST Scale function: Set Tare and Switch to Net Indication None 37
SV Auto-transmit: Send Valley Value None 41
SW Auto- transmit: Send Data String „Net/Gross/Status“ continuously None 41
SZ Scale function: System Zero Point None 37
TD Communication: Transmission delay 0…255 ms 46
TE Trigger function: Trigger on Rising Edge (1) or Falling Edge (0) 0 or 1 49
TH Trigger Hold (save the actual weight/reading) 40
TI Trigger function: Averaging Time for Automatic Taring 0...65535 ms 38
TL Trigger function: Trigger Level 0...999999 50
TN Non Volatile Tare value ON/OFF @ power OFF 0 or 1 38
TR Trigger function: Software Trigger None 49
TW Trigger function: Window for Automatic Taring 0...65535 38
UR Update Rate (average of 2 exp. ‘n’ values – 2 exp 7 = 128) 0...7 36
WP Save the Setup Data (FL, NR, NT, AD, BR, DX) to the EEPROM None 48
ZI Initial Zero Setting ON/OFF 0 or 1 32
ZN Non Volatile Zero Value ON/OFF @ power OFF 0 or 1 37
ZR Calibration: Zero Range 0...999999 32
ZT Zero Tracking – disable (0), enable (1 – legal for trade) or 2 …255 0…255 32
New Commands
SU Store User Setup incl. calibration non-volatile in EEPROM None 33
RU Restore User Setup to DAD 141.1 None 33
