DAD 141.1 Technical Manual, Rev. 2.2 - February 2014 Page 16 of 54
7.4. Menu 2
– System Span
Remark: Activate a new calibration with 1x Power OFF/ON !
2. SPAN setup (Menu 2.1 to 2.4) TAC protected – see chapter 4.12
2.1 Set SPAN Calibration value (command CG)
- Set display value equivalent to calibration weight or to mV/V value
derived from load cell(s) test data
2.2 Calibrate system SPAN - gravimetric by weight / load
- Display shows the actual input signal in mV/V
- Apply test weight equivalent to calibration value (2.1)
- Press ENTER button to store new SPAN signal.
2.3 Calibrate system SPAN - electronic by mV/V input (command AG)
- Use the UP/DOWN & MOVE RIGHT keys to setup the mV/V value at
which the device should read SPAN
- Press ENTER button to store new SPAN signal.
2.4 Display the input signal in mV/V
This function displays the actual input signal
7.5. Menu 3
– Display
Remark: Activate a new calibration with 1x Power OFF/ON !
3. Display setup (Menu 3.1 to 3.3) TAC protected – see chapter 4.12
3.1 Display limits - Overrange / Underrange (commands CM/CI)
3.1.o Display overrange limit (maximum value +999999)
Use the UP/DOWN & MOVE RIGHT keys to setup the maximum
display value, above which the display shows over range (all
dashes in the top of the display).
3.1.U Display underrange limit (minimum value -999999)
Use the UP/DOWN & MOVE RIGHT keys to setup the minimum
display value, above which the display shows under range (all
dashes in the bottom of the display).
3.2 Display step size - in digits [d] (command DS)
- choose one out of 1, 2, 5, 10, 20, 50, 100, 200, 500
3.3 Decimal point position on the display (command DP)
- choose one out of 0, 0.0, 0.00, 0.000, 0.0000, 0.00000
