Manual PC6D CANopen Page 45
5.11 Save calibration, setup & setpoint parameters Commands – CS, WP, SS
The setup and calibration parameters can be divided into 3 groups:
Calibration parameter: CZ, CG, DS, DP & ZT are saved by the CS command.
Setup parameters (other than setpoint): FL, FM, NR, NT, BR, AD, etc. are saved by the
WP command.
Setpoint parameters: Sn, Hn and An are saved by the SS command.
CS
Save the calibration parameters
[ 2004sub02 ]
Note: Calibration parameters can only be saved if the TAC code is known and precedes the
CS command. See the CE and CS commands on
page 27 / 29.
Both the setup parameters and the setpoint parameters are stored in EEPROM using the WP
and SS commands respectively.
WP
Save the setup parameters
[ 2004sub03 ]
With this command the settings of the “Filter” (FL, FM) , the “No-Motion” (NR, NT) and the
communication (AD, BR) will be saved in the EEPROM.
Master (PC / PLC) sends
Device responds
Result
WP OK
Parameter saved
WP ERR
Error
SS
Save the “setpoint” set-up parameters
[ 2004sub05 ]
With this command the settings of the setpoints (Sn), the “setpoint hysteresis” (Hn) and the
“setpoint action” (An) will be saved in the EEPROM.
Master (PC / PLC) sends
Device responds
Result
SS OK
Parameter saved
SS ERR
Error
