Page Manual PC6D CANopen 28
DP Set decimal point position [ 2300sub0B ]
This command allows the decimal point to be positioned anywhere between leftmost and
rightmost digits of the 5-digit output result. Position 0 means no decimal point.
Master (PC / PLC) sends Device responds Result
DP P+00002 Request : position of dec. point
CE E+00017 (example) Request: TAC-counter CE 17
CE_17 OK Calibration sequence active
DP_0 OK Setting: no decimal point
CZ Set calibration zero point [ 2300sub0A ]
This is the reference point for all weight calculations, and is subject to TAC control.
Master (PC / PLC) sends Device responds Result
CE E+00017 (example) Request: TAC-counter CE 17
CE_17 OK Calibration sequence active
CZ OK Zero point set
Factory default: approx. 0 mV/V input signal
CG Set calibration gain (span) value [ 2300sub04 ]
This is the reference point for calibration under load, and is subject to TAC control.
Permitted values are 1…250000.
Master (PC / PLC) sends Device responds Result
CG G+20000 Request : span 20000d
CE E+00017 (example) Request: TAC-counter CE 17
CE_17 OK Calibration sequence active
CG_50000 OK Setting: span 50000d
For calibration an input signal near the display maximum (CM) will give the best system
performance. The minimum calibration load of at least 20% is recommended.
Factory correct calibration default: 200000 d = 2.000 mV/V input signal = 20 kg
ZT Zero tracking [ 2100sub12 ]
This command enables or disables the zero tracking. Parameter = 0 disables the zero
tracking and parameter = 1 enables the zero tracking. Issuing the command without any
parameter returns the current ZT value.
Master (PC / PLC) sends Device responds Result
ZT Z:001 Request : ZT status (ON)
CE E+00017 (example) Request: TAC-counter CE 17
CE_17 OK Calibration sequence active
ZT_0 OK Setting: ZT = OFF
