Manual PC6D CANopen

Page 15

Index Sub-

index

Name

Type

Attri-

bute

Default-

value

Meaning

2000

0
1

2
3

4
5

Number of entries
Gross weight

Net Weight
Tare

Dosed weight
Dosed tare

Average weight

UI8
REAL32

REAL32
REAL32

REAL32

ro
ro

Number of entries in command input array.
Weight values as 32 bit IEEE754 floating point.

Dosed values always read 0 (zero) on PC6D

2001

0
1
2

3
4

5
6

7
8

9
A
B

Number of entries
Gross weight
Net Weight

Tare
Dosed weight

Dosed tare
Average weight

A/D sample
H&B Device ID

H&B FW Version
Device Status
ADC Reference

UI8
I32
I32

I32
I32

I32
I32
I32

ro
ro
ro

ro
ro

ro
ro
ro

Number of entries in info array.
Weight and info values as 32 bit signed integer

Dosed values always read 0 (zero) on PC6D

2002

0
1

2
3

Number of entries
1

Object

UI8
UI16

UI8
UI8

ro
ro

Number of objects in the dosed result.
Module Status

Data source (0=average,1..4=setpoints).
-*

Gateway Status

-*this field reads 0 (zero) on PC6D

2003

0
1..16

Number of entries
Hardware ID bytes

UI8
UI8

ro
ro

Number of bytes in hardware identification array.
