Manual PC6D CANopen Page 18
Index Sub-
index
Name Type Attri-
bute Default-
value Meaning
2300
0
1
2
3
4
5
6
7
8
9
A
B
C
D Number of entries.
Absolute gain
Absolute zero
Calibrate enable
Calibrate gain
Set calibration point B
Set calibration point A
Calibrate max
Calibrate min
Calibrate save
Calibrate zero
Decimal point
Display step size
Local gravity UI8
I32
I32
I32
I32
I32
I32
I32
I32
I32
I32
I32
I32
I32
ro
rw
rw
rw
rw
rw
rw
rw
rw
rw
rw
rw
rw
rw 12
Number of calibration parameters.
-
* Absolute gain calibrate (TAC protected)
- * Absolute zero calibrate (TAC protected)
Calibrate enable (enables TAC when the TAC is written)
Calibrate gain (TAC protected)
-
* Set calibration point B
- * Set calibration point A
Calibrate max (TAC protected)
Calibrate min (TAC protected)
Calibrate save (TAC protected)
Calibrate zero (TAC protected)
Decimal point (TAC protected)
-
* Display step size (TAC protect)
Adjust calibration of zero and gain according to new entered gravity
vs. gravity of factory calibration. Remark: Proceeding factory default
(2006 sub 2) changes local gravity back to factory calibration.
-*not implemented on PC6D
2500
0
1
2
3
4
5
6
7
8
Number of entries.
Trigger Level
Trigger Egde
ReTrigWindow
ReTrigTime
HoldTime
TareWindow
TareTime
ReTrigStop
UI8
I32
I32
I32
I32
I32
I32
I32
I32
ro
rw
rw
rw
rw
rw
rw
rw
rw
8 Number of Check-Weigher parameters
Trigger Level
Trigger Egde
ReTrigWindow
ReTrigTime
HoldTime
TareWindow
TareTime
ReTrigStop
