Flintec PC6D - Manual (Page 21)

Manual PC6D CANopen Page 21
Index Sub-
index
Name Type Attri-
bute
Default-
value
Meaning
6401
0
1
2
3
4
5
6
Number of entries
Gross weight
Net Weight
Tare
Dosed weight
Dosed tare
Average weight
UI8
I16
I16
I16
I16
I16
I16
ro
ro
ro
ro
ro
ro
ro
6 Number of entries in the 16 bit analog input module
These entries are mandatory according to DS401. They are the same
as for index 6402, but shifted 8 bits to the right (value/256).
Dosed values always read 0 (zero) on PC6D
6402 0
1
2
3
4
5
6
7
Number of entries
Gross weight
Net Weight
Tare
Dosed weight
Dosed tare
Average weight
A/D sample
UI8
I32
I32
I32
I32
I32
I32
I32
ro
ro
ro
ro
ro
ro
ro
ro
7 Number of entries in the 32 bit analog input module
These values are the internal long integer representation of the
weight (the integer values are multiplied by 10^dp [2300sub0B]).
Index 6402 is a sub-set of index 2001.
Dosed values always read 0 (zero) on PC6D
6403
0
1
2
3
4
5
6
Number of entries
Gross weight
Net Weight
Tare
Dosed weight
Dosed tare
Average weight
UI8
REAL32
REAL32
REAL32
REAL32
REAL32
REAL32
ro
ro
ro
ro
ro
ro
ro
6
Number of entries in the float analog input module
These values are the floating-point representation of the weight as
they are transmitted in the PDO1(tx).
Index 6403 is a replica of index 2000.
Dosed values always read 0 (zero) on PC6D
