Mode 1 Characteristic (FIR-Filter)
FL
Settling time
to 0.1%
(ms)
3 dB Cut-off
(Hz)
20 dB
damping at
frequency
(Hz)
40 dB
damping at
frequency
(Hz)
Damping in
the
stopband
(dB)
Stopband
(Hz)
Output rate
max.
(samples/s)
0 no
filtering **
1200
1 47
19.7 48 64
>90
>80
1200
2 93
9.8 24 32
>90
>40
600
3 140
6.5 16 21 >90
>26
400
4 187
4.9 12 16 >90
>20
300
5 233
3.9 10 13 >90
>16
240
6 280
3.2
8 11 >90
>13
200
7 327
2.8
7 9 >90
>11
172
8 373
2.5
6 8 >90
>10
150
* * Antialiasing filter 17 Hz @ 60 dB/decade
Attention: In mode 1 the output rate is dependant on the selected filter level (FL) and will be
automatically adjusted by the PC6D.
UR
Set the update rate (average building)
[ 2100sub11 ]
This command will define over how many measurements, from the preceeding IIR or FIR
filter, an average will be calculated. The average will be calculated over 2
UR
samples.
Permitted values 0...7 (see table below).
UR
0
1
2
3
4
5
6
7
No. of samples
1
2
4
8
16
32
64
128
Check / adjustment update rate:
Master (PC / PLC) sends
Device responds
Result
UR U+0001
Request: average over 2 samples
UR_4 OK
Setting: average over 16 samples
Factory default: 0 [no average, = 1200 samples/s]
Remark to Mode 1
Dependency Output Rate - averaging UR - Filter FL
UR
Output Rate samples/s
FL0
FL1
19.7 Hz
FL2
9.8 Hz
FL3
6.5 Hz
FL4
4.9 Hz
FL5
3.9 Hz
FL6
3.2 Hz
FL7
2.8 Hz
FL8
2.5 Hz
0
1200
1200 600 400 300 240 200 172 150
1
600 600 300 200 150 120 100 85.7 75
2
300 300 150 100 75 60 50 43 37.5
3
150 150 75 50 37.5 30 25 21.4 18.7
4 75 75 37.5 25 18.7 15 12.5 10.7 9.4
5 37.5 37.5 18.7 12.5 9.4 7.5 6.26 5.36 4.68
6
18.7 18.7 9.4 6.26 4.68 3.76 3.12 2.68 2.34
7 9.4 9.4 4.68 3.12 2.34 1.88 1.56 1.34 1.18
