Communication profile (tables) – Flintec PC6D User Manual
Page 11

Manual PC6D CANopen
Page 11
Communication Profile (Tables)
Index Sub-
index
Name
Type
Attri-
bute
Default-
value
Meaning
1000
0
Device Type
UI32
ro
00040191H
Device Type
1001
0
Error Register
UI8
ro
0
0: No error
Bit 0: General error in Gateway Module
Bit 4: Error in CAN communication module
Bit 7: Manufacturer-specific error
1005
0
COB-ID Sync messg.
UI32
rw
80H
COB-ID of the SYNC object
1006
0
Communication cycle
Period
UI32
rw
50000
Minimum interval between TDPO1 (default 20Hz).
Min=833 (1200Hz rate).
100C
0
Guard Time
UI16
rw
320
Cycle time in ms, set by the NMT Master or the configuration tool.
100D 0
Life Time Factor
UI8
rw
3
Wait time is set by the NMT Master or the configuration tool.
100E
0
Node guarding
identifier
UI32
rw
0x700 +
NodeID
Node guarding identifier
1014
0
COB-ID Emergency
Message
UI32
rw
80H +
NodeID
COB-ID of the Emergency Object
1017
0
Heartbeat Time
UI16
rw
0
Producer Heartbeat time. If index 1017h is nonzero Heartbeat is
used, else Node-guard protocol is used.
1018
0
1
2
3
4
Identity Object
Vendor ID
Product Code
Revision Number
Serial Number
UI8
UI32
UI32
UI32
UI32
ro
ro
ro
ro
ro
4
Number of entries
Vendor ID
Product Code
Revision Number
Serial Number
1400
0
1
2
Number of elements
COB-ID
Transmission type
UI8
UI32
UI8
ro
ro
ro
2
80000200H
+ NodeID
FFH
Communication parameters of 1st Receive PDO
Determined using the CANopen minimum system ID assignment
procedure.
Asynchronous communication.
1401
0
1
2
Number of elements
COB-ID
Transmission type
UI8
UI32
UI8
ro
ro
ro
2
80000300H
+ NodeID
FFH
Communication parameters of 2
nd
Receive PDO
Determined using the CANopen minimum system ID assignment
procedure.
Asynchronous communication.
