C-PRO GIGA HARDWARE MANUAL
Pag. 31
Lower board 24 VAC/DC power supply version with built-in switching feeder
Conn.
Letter
code
Description
CA-1 VCC main card power supply (24Vac/dc)
CA-2 VCC main card power supply (24Vac/dc)
Top board
Conn.
Letter
code
Description
JN-1 NC 9 normally closed contact relay no. 9
JN-2 COM 9 common relay no. 9
JN-3 NO 9 normally open contact relay no. 9
JO-1 NC 10 normally closed contact relay no. 10
JO-2 COM 10 common relay no. 10
JO-3 NO 10 normally open contact relay no. 10
JP-1 COM 11 common relay no. 11
JP-2 NO 11 normally open contact relay no. 11
JP-3 COM 12 common relay no. 12
JP-4 NO 12 normally open contact relay no. 12
JP-5 COM 13 common relay no. 13
JP-6 NO 13 normally open contact relay no. 13
JQ-1 DI 11 digital input no. 11 230 Vac
JQ-2 DI 12 digital input no. 12 230 Vac
JQ-3 COMHV common terminal for 230Vac digital inputs
Jumper and LED meaning
In the controller some configuration jumpers are mounted:
JMP3 CAN termination
Jumper not inserted (120
Ω
) termination not inserted
Jumper inserted (120
Ω
) termination inserted
JMP4 Internal serial CAN Baud Rate selection
A
B
Jumper A inserted
Jumper B inserted
Baud rate = 20K
A
B
Jumper A inserted
Jumper B not inserted
Baud rate = 50K
A
B
Jumper A not inserted
Jumper B inserted
Baud rate = 125K
A
B
Jumper A not inserted
Jumper B not inserted
Baud rate = 500K
