C-PRO GIGA HARDWARE MANUAL
Pag. 24
Detection time from ON to OFF 100 ms
Note: The commons (COM) terminals are connected together
Number 2
type optoinsulated
Voltage range 100 - 240 Vac
Detection time from OFF to ON 100 ms
High voltage Digital
Inputs
Detection time from ON to OFF 100 ms
Number 4
type voltage or current
(selectable by dip-switch),
optoinsulated
Jumper inserted Current
Current range 0 - 20 mA
Current output accuracy ±1 mA
Current output resolution 0.05 mA
Maximum load of current output 50 - 250Ω
Current output setting time 1 sec
Jumper not inserted Voltage
Voltage range 0,5 - 10 V
Voltage output accuracy ±200 mV (without load)
Voltage output resolution 10 mV
Maximum load of voltage output 200Ω
Voltage output settling time 1 sec
Analog outputs
Note:
1) not protected output against permanent short circuit
2) ((Zl/(Zo+Zl) use load with impedance Zl>1K
Ω
Number 13
type electromechanical relays
With NO contacts 9
With SPDT contacts 4
Contact ratings : relays 1 to xx 2000VA 250Vac, 8A
cos
θ
=1
Contact ratings : 2000VA 250Vac, 8A
cosφ=1
6(4) accordino to
EN60730-1
Contact life cycles > 100000
Digital outputs
Note:
1)The commons (COM) terminals are not connected together
2) Main insulation is guaranteed between the relays
3) Two relays are 5A
Number
1
type CAN V2.0B
no optoinsulated
Physical layer 2 wires + common wire
(ISO 11898)
Internal CAN
communication bus
Baud rate (max. length = 10 m) 20K
