C-PRO GIGA HARDWARE MANUAL
Pag. 15
Wide CAN port (on request)
Conn.
Letter
code
Description
YD-1 CAN0+ CAN + terminal Wide CAN port
YD-2 CAN0- CAN - terminal Wide CAN port
YD-3 GND* GND terminal Wide CAN port
Second RS-485 port(on request)
Conn.
Letter
code
Description
YE-1 RS485- RS 485 - serial serial port terminal
YE-2 RS485+ RS 485 + serial port terminal
YE-3 GND* GND serial port terminal
RS-232 port (on request, alternative to second RS-485 port)
Conn.
Letter
code
Description
YF-1 5Vdc RS 232 9-pin connector -
YF-2 Tx RS 232 9-pin connector – Transmitting data
YF-3 Rx RS 232 9-pin connector – Receiving data
YF-4 DTR/DSR RS 232 9-pin connector -
YF-5 GND RS 232 9-pin connector -
YF-6 DTR/DSR RS 232 9-pin connector -
YF-7 RTS RS 232 9-pin connector -
YF-8 CTS RS 232 9-pin connector -
