EVCO EVB1256N9 User Manual
Page 23
EVCO S.p.A.
EVBOX1 | Installation guide ver. 1.2 | Code 144BOX1E124
page 23 of 88
u1
in the EVB1204N9 and EVB1214N9 models, the application is managed through
the K4 digital output
0
=
man in cold room exit
1
=
demister heating elements
2
=
auxiliary output
3
=
alarm output
4
=
door heating elements
5
=
neutral area operating heating elements
6
=
condenser fan
7
=
compressor 2
8
=
defrosting2
9
=
evaporator fan 2
10
=
pump down valve
11
=
on/stand-by
12
=
man in cold room exit
0
u1
in the remaining models, the application is managed by the K5 digital output
0
=
reserved
1
=
demister heating elements
2
=
auxiliary output
3
=
alarm output
4
=
door heating elements
5
=
neutral area operating heating elements
6
=
condenser fan
7
=
compressor 2
8
=
defrosting2
9
=
evaporator fan 2
10
=
pump down valve
11
=
on/stand-by
12
=
man in cold room exit
5
u11
if present, the application is managed by the K6 digital output
0
=
reserved
1
=
demister heating elements
2
=
auxiliary output
3
=
alarm output
4
=
door heating elements
5
=
neutral area operating heating elements
6
=
condenser fan
7
=
compressor 2
8
=
defrosting2
9
=
evaporator fan 2
10
=
pump down valve
11
=
on/stand-by
12
=
man in cold room exit
2
Then, check that the remaining settings are appropriate; refer to paragraph 12.5 “List of configuration parameters”.
6.
Connect the loads power supply
7.
Turn the device on; refer to paragraph "Device switch-on/off in manual mode".
For additional information, please refer to the following paragraphs.
