Index 74
Numerics
10/100M bps Ethernet 60
A
accessing
ATS-NTE with NetMeeting 14
adapters, supported
Xircom CreditCard Wireless Ethernet adapter
(CWE1130-NA) 41
Xircom RealPort Modem 56 GlobalACCESS 46
agency notices 63
air temperature 59
altitude 59
AUX A port
default baud 59
pinouts 55
reconfigure as standard serial port 48
required setup 11
B
baud rates
default 59
BIOS 60
changing configuration 67 – 73
building
DB25loopback plugs 30
DB9 loopback plugs 29
null-modem cable 31
RJ45 loopback plugs 30
RS-485 test cable 30
straight-through cable 31
C
cables
build null-modem 31
build RS-485 test cable 30
build straight-through 31
changing
BIOS configuration 67 – 73
default computer name 9
network settings 8
PC104 name 21
Starting COM port number
PC104 21
workgroup name 9
client
setup 13
Xircom wireless
change name 42
Clone 19
COA label 53
COM1-3
default baud 59
COM4-11 port properties
PC104 18
COM4-COM11
baud rate range 59
compact flash
size options 59
usage caution 14
compact flash connector 55
computer name
changing default 9
configuration
changing BIOS 67 – 73
client setup 13
default operating system 60
Ethernet ports 8
NetMeeting 14
NetMeeting setup 10
network settings 8
PC104 COM port properties 18
PC104 serial ports 18
RAS TCP/IP 11
Xircom wireless adapter 41
connecting serial devices 22
connectors 54 – 57
CONSOLE port
default baud 59
how to use 49
pinouts 55
reconfigure as a COM port 50
current
consumption 59
D
DB25 connectors
loopback plugs
PC104 30
PC104 29
DB9 connectors
loopback plugs
PC104 29
PC104 29
straight-through cables 31
diagnostics 52
dialin
NetMeeting configuration 10
dimensions 59
display controller 60
documentation updates 53
downloads 53
drivers
installing modem 26
PC104 version 18
PCMCIA 6
printer default 6
dual-Ethernet ports 8
E
electromagnetic compliances 58
email
Technical Support 53
emission 58
environmental conditions 59
Index
