Appendix A. Connectors 55
Compact Flash Disk Connector
Compact Flash Disk Connector
This table illustrates the compact flash connector pinouts.
AUX A and CONSOLE Port Connectors
This table illustrates the DB9 pinouts for the AUX A and CONSOLE connectors.
Pin Signal Pin Signal
1 Ground 26 VCC-IN, CHECK1
2 DATA 3 27 DATA 11
3 DATA 4 28 DATA 12
4 DATA 5 29 DATA 13
5 DATA 6 30 DATA 14
6 DATA 7 31 DATA 15
7 HDC_CS0# 32 HDC_CS1
8 Not connected 33 Not connected
9 Ground 34 IOR#
10 Not connected 35 IOW#
11 Not connected 36 Not connected
12 Not connected 37 Interrupt
13 VCC_COM 38 VCC_COM
14 Not connected 39 CSEL
15 Not connected 40 Not connected
16 Not connected 41 HDD_RESET
17 Not connected 42 IORDY
18 SA2 43 N/C
19 SA1 44 VCC_COM
20 SA0 45 HDD_ACTIVE#
21 DATA 0 46 Not connected
22 DATA 1 47 DATA 8
23 DATA 2 48 DATA 9
24 Not connected 49 DATA 10
25 VCC-IN, CHECK2 50 Ground
Pin Signal Pin Signal Pin Signal
1 CD 4 DTR 7 RTS
2 RxD 5 Ground 8 CTS
3 TxD 6 DSR 9 RI
