Appendix B. Specifications and Notices 59
Environmental Condition Specifications
Environmental
Condition
Specifications The following table illustrates environmental condition specifications for the
DeviceMaster ATS-NTE.
Hardware
Specifications This table lists hardware specifications for the ATS-NTE.
Technical
Specifications This subsection lists the DeviceMaster ATS-NTE technical specifications.
• Compact flash (256 MB or 512 MB) with pre-configured Windows NT
Embedded operating system. See
Default Operating System Configuration on
Page 60 for detailed information.
• NS GXLV/GX1-300 MMX 32-Bit x86 Processor that supports the Intel
®
MMX
instruction set extension for the acceleration of multi media applications. It
has 16 KB unified L1 cache, five-stage pipe lined integer unit, and an
integrated Floating Point Unit (FPU).
• 128 MB SDRAM system memory
Environmental Condition Value
Air temperature:
System on (operational)
System off (storage)
0 to 60
o
C
-20 to 85
o
C
Altitude 0 to 10,000 feet
Heat output 47 BTU/Hr
Humidity (non-condensing):
System on (operational)
System off (storage) 8% to 80%
20% to 80%
Specification Description
Baud rates (default):
COM1 - AUX A
COM2 - CONSOLE
COM3 - PCMCIA modem
(optional)*
COM4 to COM11 - SERIAL PORTS
1-8 (optional)
57.6 Kbps
28.8 Kbps
57.6 Kbps
300 bps to 230.4 Kbps
Optional PC104 driver control
Data bits: 7 or 8
Parity: Odd, even, none
Stop bits: 1 or 2
Power input:
Frequency
Voltage 50/60 Hz
5 VDC
Power consumption 13.75 W
Current consumption 2.75 A
Dimensions 11” x 5.69” x 2.75” (W x L x H)
Weight:
Fully-configured system with
RocketPort PC104 and
PCMCIA options installed
Power supply
Octacable
3.52 lbs
0.62 lbs
1.12 lbs
* See Certified PCMCIA Adapters on Page 41 for the list of Comtrol
approved adapters.
