Front Panel

Explanations can befound in the page indicated in parentheses.

UD-NF7 is illustrated.

Wi-Fi areai (UD-NF7 oniy) Button (p. 7)

tì (Power) Button

(p. 10,12,14-16, 21,29, 32-39,

44)

TiMER LED (p. 38)

Disc Tray (p. 23)

Dock for iPod/iPhone (p. 20)

Voiume Controi (p. 10,18, 22)

USB/iPad Terminai (p. 20, 29, 30)

AUDiO iNTerminai (p. 41)

PHONES Terminai (p. 41)

® iNPUT (Function) Button (p. 8,11,21,

29, 41)

® ^Button(p.12,18,22,24,27,29,

30, 32-39)

® ^Button(p.12,18,22,24,27,29,

30, 32, 38, 39)

® ■ Button (p. 24-27, 29, 30)

® ^/H Button(p.10,18,21-26,29,

30)

® ^ Button(p.23,27,44)
