Page 88
6-2
SMC Installation and User's Guide
6.1
Set Up the Modem
Follow the manufacturer’s instructions for cabling the modem.
Figure 6–1 COM2 Port
PK-1735A-00
COM2 (B)
COM2 (B)
Minitower
Model DPENM
Desktop Box
Model DPEND
Minitower
Model DPENCM
Desktop Box
Model DPENL
COM2 (B)
COM2 (B)
NOTE: The model type is on a label on the top or side of the SMC box.
1.
Cable the modem, following the manufacturer’s instructions. Connect the
RS-232C cable from the SMC installation kit to COM2 on the SMC system
(Figure 6–1; COM2 might be marked B).
